Hydroponic Controller (HMI)

MC Series — HMI touchscreen

Six 5A relays sized for a grow room — fogger, air circulation fan, NFT pump, growbag irrigation, grow light and sprinkler on one controller.
Independent run and rest timers per output — each cycle set in minutes on screen, so nutrient and misting schedules need no external timers.
Temperature and humidity on two 4-20mA channels — with high and low alarm states shown live on the home screen.
Capacitive touchscreen in 4.3 or 10 inch — every output shows its ON/OFF state and remaining time at a glance.

Tags hydroponic controller, HMI, touchscreen, NFT pump, fogger, grow light, sprinkler, 4-20mA, vertical farming

Brand MIGCON

Technical specifications for the Hydroponic Controller (HMI)
Power Supply	12 Vdc operated
Sensor Input	2 channel (4-20mA) for temperature / humidity
Control Relay	6 nos (rated 5 Amp) for fogger / ACF / NFT / growbag / grow light, sprinkler
Touch Screen Display	Two options — 4.3 inch or 10 inch, capacitive touch control for realtime view and programming of parameters
Dimensions	4.3 inch — 100 × 136 × 70 mm; 10 inch — 264 × 178 × 40 mm
